Processing pipe diameter >1000mm， Prcoessing bevel type : V/K/J and milling edge
GPM-60L Pipe beveling machine introduction:
Portable beveling machine for fast processing of large pipeline bevels, bidding farewell to the small processing range of ordinary pipe beveling machines, has caused customers the worry of high procurement costs. The GPM-60L beveling machine processing speed of pipeline groove can be adjusted between 0-1500mm/min, with a single processing depth of 8mm for 30 degree carbon steel pipeline groove, and a linear speed of 700mm/min.
GPM-60L Pipe beveling machine technical parameters:
Power Supply: AC380V 50HZ or AC220V or AC415V
Total Power: 3520W
Special Functions: Auto clamping plate
Processing Pipe Tc=hickness: 6~60mm
Processing Pipe DIA: >1000mm
Pipe Height: > 300mm
Bevel Angle: 0~90 degree
Processing Bevel type: V, K, U/J
Net Wwight: 185kg
